Introduction to Polkatool

Banner for Introduction to Polkatool

Language: English

Author: Tin Chung

Level: Intermediate

Polkatool is the command-line utility used in the PolkaVM ecosystem to transform compiled guest programs (ELF/object files) into the PolkaVM module/blob format (.polkavm), and to inspect/disassemble those blobs. It’s part of the PolkaVM toolchain used by projects (Rust contracts, Move/LLVM backends, PVQ, etc.) and is commonly used during a build → link → deploy workflow (Reference: https://forum.polkadot.network/t/announcing-polkavm-a-new-risc-v-based-vm-for-smart-contracts-and-possibly-more/3811?utm_source=chatgpt.com#p-9222-the-compilation-pipeline-7).

Before you start — prerequisites

You’ll typically need:

  • Rust toolchain (stable + appropriate target).
  • cargo installed and ~/.cargo/bin on your PATH.
  • polkatool (installed via cargo install or built from the PolkaVM repo).
  • For some language backends (Move/LLVM) you may need LLVM & clang toolchain (depends on the project).

Installation

  1. Install from crates.io (recommended for most devs)
# install the latest published polkatool binary
cargo install polkatool
# ensure ~/.cargo/bin is on your PATH

crates.io shows recent published versions and cargo install is the usual path.

  1. Build & install from the polkavm repo (useful if you need unreleased features)
git clone https://github.com/paritytech/polkavm.git
cd polkavm/tools/polkatool
cargo install --path .
# or for development:
cargo build
# run via: cargo run -p polkatool -- <args>

This is handy for bleeding-edge or when you need to match a particular polkavm commit. After installing the polkatool binary, you will find the command’s details in your local machine:

➜ polkatool
Usage: polkatool <COMMAND>

Commands:
  link                  Links a given ELF file into a `.polkavm` program blob
  disassemble           Disassembles a .polkavm blob into its human-readable assembly
  assemble              Assembles a .polkavm blob from human-readable assembly
  stats                 Calculates various statistics for given program blobs
  get-target-json-path  Writes a path to a JSON target file for rustc to stdout
  help                  Print this message or the help of the given subcommand(s)

Options:
  -h, --help     Print help
  -V, --version  Print version

Typical workflow: Rust contract → .polkavm

The common flow (Rust examples) is:

  1. Write your guest program (Rust no_std style or using a template that targets the PolkaVM syscalls / hostcalls).
  2. cargo build to produce an ELF (for the correct target).
  3. Use polkatool link (or polkatool subcommand intended for linking) to convert and optimize the ELF into a .polkavm blob.
  4. Deploy the .polkavm file to chain via RPC tools (e.g., cast/Foundry or custom tool) or via the chain UI.

Example (from parity’s rust-contract-template)

Assuming the repo uses a Makefile that runs cargo build and then polkatool link:

# 1. Install polkatool if you haven't
cargo install polkatool

# 2. Build Rust contract
cargo build --release

# 3. The ELF will typically be at target/(your-target)/release/<binary>
#    Use polkatool to link -> outputs contract.polkavm (artifact name varies)
polkatool link target/(your-target)/release/your_contract -o contract.polkavm
# result: contract.polkavm

Notes: The link step typically strips unused sections, optimizes, repacks, and emits the .polkavm format that the runtime expects (this is the core role of polkatool in the toolchain).

Inspecting and disassembling blobs

Polkatool also provides inspection/disassembly features — very useful during development and debugging.

Example commands (typical usage patterns shown in community examples and discussions):

# Disassemble or inspect a blob
polkatool disassemble contract.polkavm     # show human-readable disassembly / metadata

# If you’re building from repo or want raw bytes:
cargo run -p polkatool -- disassemble --show-raw-bytes ./path/to/blob.pvm

If polkatool reports “blob doesn't start with expected magic bytes” it usually means the file is not a PolkaVM container or you passed the wrong artifact (e.g., raw ELF instead of .polkavm). Use file/xxd to confirm the data if needed. (Reference: https://paritytech.github.io/matrix-archiver/archive/_21wBOJlzaOULZOALhaRh_3Apolkadot.io/index.html?utm_source=chatgpt.com)

Experiment with Polkatool

# 1. Install polkatool
cargo install polkatool

# 2. Create a minimal rust-contract-template-based project:
git clone https://github.com/paritytech/rust-contract-template.git my-rust-contract
cd my-rust-contract

# 3. Build
cargo build --release

# 4. Link into .polkavm (Makefile usually automates this, but manual command pattern:)
polkatool link target/release/<binary> -o contract.polkavm

# 5. Inspect
polkatool disassemble contract.polkavm

# 6. Deploy (example: using cast)
PAYLOAD=$(xxd -p -c 99999 contract.polkavm)
cast send --account dev-account --create "$PAYLOAD"

Deploying .polkavm to a chain (Foundry / cast example)

It is recommended for you to read the tutorial on how to use Foundry with Polkadot Hub first before continuing the section below: https://docs.polkadot.com/develop/smart-contracts/dev-environments/foundry/

Polkadot documentation and templates often use Foundry’s cast (or other eth-rpc tools) to deploy PolkaVM blobs because Asset Hub’s eth-compat tooling accepts hex blob payloads.

Example pattern from the rust-contract-template:

# turn the .polkavm file into a hex payload for create tx
PAYLOAD=$(xxd -p -c 99999 contract.polkavm)

# deploy via cast / eth-rpc endpoint
export ETH_RPC_URL="https://<asset-hub-eth-rpc>"
export ETH_FROM=<your-account>

# create a contract
cast send --account <account> --create "$PAYLOAD"
# returns contract address

And to call

cast call <contractAddress> "fibonacci(uint32) public pure returns (uint32)" 4

This shows how the .polkavm blob is encoded into the same deployment path used by EVM-like eth_create RPCs on chains that support PolkaVM/eth-compat layers.

Advanced workflows & integrations

Move, LLVM and other languages

  • Projects exist that compile Move (via LLVM) to RISC-V object code and then rely on polkatool to link into .polkavm. These pipelines require LLVM toolchain and additional conversion steps. Example: polkavm-move shows how Move → LLVM → RISC-V objects → polkatool link. (Reference: https://github.com/eigerco/polkavm-move?utm_source=chatgpt.com)

PVQ / Cross-consensus programs

  • PVQ (open-web3-stack) demonstrates using polkatool in a chain of tools to produce PVM blobs for queries (it uses make tools that installs polkatool to do ELF → PolkaVM conversion). Useful when integrating PolkaVM guest programs into larger test runtimes. (Reference: https://github.com/open-web3-stack/PVQ)

Solana / other ecosystems

  • Community projects have used polkatool to convert pre-built binaries from other ecosystems (e.g., Solana anchor programs) into PolkaVM blobs for prototype cross-Vm runtime experiments — typically by compiling to ELF/object with appropriate target and then linking. (Reference: https://github.com/LollipopHQ/sbpf-on-polkavm?utm_source=chatgpt.com)

Debugging & testing tips

  • Check magic bytes / header before assuming polkatool will accept a file — the linker expects a particular container format. If disassemble fails, confirm you passed a polkavm file not raw ELF.
  • Use polkatool disassemble to inspect entry points, exported symbols, and metadata.
  • Use small, iterative builds — the linker can strip a lot but debugging optimized stripped blobs is harder; keep a debug build when stepping through logic.
  • Use mock hostcall test harnesses when unit-testing guest logic — community repos provide hostcall stubs / PVQ test runners.

Common issues & troubleshooting

  • polkatool not found after cargo install — ensure ~/.cargo/bin is on your PATH.
  • Disassemble fails with “magic bytes” — you passed a wrong artifact (e.g., ELF). Run file contract.polkavm or xxd to inspect the header.
  • Missing LLVM when compiling Move or other backends — install the LLVM dev packages (distribution-specific) before building those backends.
  • Runtime incompatibility — polkavm and pallet_revive / runtime integration are evolving. Make sure the polkatool version matches the runtime chain expectations (e.g., gas model changes, container format updates). Check PolkaVM release notes and chain docs for the right version. docs.polkadot.com+1
